| Business Type | Exporter, Supplier |
| Pressure | Up To 10 Kg/cm2 |
| Capacity | Up to 1400M3/ HR |
| Head | Up to 100 Mtrs |
| Click to view more | |
Product Details
-
VERTICLE SUMP PUMPS / SUBMERGED PUMPS
WORKING PRINCIPLE:Vertical sump pumps, also known as submersible pumps, work by using a submerged impeller that rotates, creating centrifugal force to propel the liquid out of the sump and up a discharge pipe.
FEATURES: Self Priming, Space Economy and Simple Mounting Design. Vertical suspended with Closed and Semi Open Impeller Construction for Wet and Dry Pit applications.Non-metallic adapter with a flange having enough outlet passages, which does not allow the liquid to flow towards the mounting plate. Vapour seal fitted between motor and the pump, thereby protecting the motor from damages due to vapour. Casing can be rotated in any discharge direction, giving it installation flexibility. Semi-open impeller with volute type casing and contoured discharge is ergonomically designed to help achieve improved efficiency and reduced energy consumption.
APPLICATIONS: Small pit transfer, tank mounted pumps for small scrubbers, spraying applications, plating shops and pickling tanks. Handling Underground Tank Liquids, Acids, Alkalis, Dyes, Hydrocarbons, Corrosive Slurries, Marble and Granite Slurries, Fertilizers, Sugar Industry, Paper & Pulp Industry, Chemical & Petrochemicals Industry, Sludge & Waste Water, Effluent, Etc.
